Speech Bubble & Cartoon Kit Bundle

Rated 5.00 out of 5 based on 2 customer ratings
(2 customer reviews)

$15.00

Add to Wishlist
Add to Wishlist

Get Speech Bubble, Cartoon Panel AND Cartoon Effect all in one discount bundle! Speech Bubble & Cartoon Kit is a set of 3 titles/effects to give your project a cartoon look.

Speech Bubble features 7 different designs of custom, animated comic book style speech bubbles. On screen controls adjust the size, position, and tail length. Control roundness, tail direction, outline colors, bubble color, and text fade animation.

Cartoon Effect adjusts detail, halftone, outline, posterization and strobing of your image to give it that animated, hand drawn or printed feel.

Cartoon Panel / Cartoon Panel Custom Shape adds a comic book style panel shape to your image. Choose from 5 standard Cartoon Panel shape options and adjust the position, rotation, scale, & outline, or choose the Cartoon Panel Custom Shape for a more user customizable comic book style panel. The custom shape supports on-screen controls to manipulate 4 corner points to affect the position and shape.  Use panel presets to stack up multiple panels into your own comic book type visual design.

COMPATIBILITY
Final Cut Pro X 10.3.4+
(contact support if you need a 10.2.3+ version)

WHAT’S INCLUDED
Download includes 3 FCP X plugins, presets and detailed instructions

Sound Effects are NOT included, but 3 similar SFX are freely available in your Final Cut Pro Sound Effects library: Bottle Cork, Cartoon Accent 17, and Cartoon Accent 26

The featured font is Komika display and can be downloaded here:
https://www.fontsquirrel.com/fonts/Komika-Display

Overview Video

Instructions

(revised 8/12/17)

Thanks for downloading the BretFX Speech Bubble & Cartoon Kit set of plugins!  I hope you enjoy them and find them useful in your productions. If these instructions don’t cover all questions about installation and usage, don’t hesitate to contact support@bretfx.com.

COMPATIBILTY
Final Cut Pro X 10.3.4+

FEATURES
Speech Bubble & Cartoon Kit consists of 3 plugins to give your project a cartoon look.

SPEECH BUBBLE includes 1 title and 12 presets

8 animated comic book style speech bubble presets, and 4 position presets. On screen controls adjust the size, position, and tail length. Control roundness, tail direction, outline colors, bubble color, and text fade animation.

CARTOON KIT includes 3 effects and 26 presets

Cartoon Effect: adjusts detail, halftone, outline, posterization and strobing of your image to give it that animated, hand drawn or printed feel.

Cartoon Panel: adds a comic book style panel shape to your image. Choose from 5 shape options and adjust the position, rotation and scale.  Control outline style, size and color.  Use panel presets to stack up multiple panels into your own comic book type visual design.

Cartoon Panel Custom Shape: adds a more user customizable comic book style panel shape to your image. On-screen controls manipulate 4 corner points to affect the position and shape.  Control outline style, size and color.  Use panel presets to stack up multiple panels into your own comic book type visual design.

FONT
The default font, and the font featured in all promo materials is Komika display and can be downloaded here: https://www.fontsquirrel.com/fonts/Komika-Display

INSTALLATION
Double click the DMG file to mount the installer and agree to the license.  Then double click the .pkg installer and follow the prompts.

The Speech Bubble plugin and its 12 position/shape presets will appear in the titles browser in FCP X under BretFX Speech Bubble.

The Cartoon Kit, which includes the BretFX Cartoon Effect and BretFX Cartoon Panel, with 26 effect and panel shape presets, will appear in the effects browser under BretFX Cartoon Kit.

SPEECH BUBBLE INSTRUCTIONS

To Apply
In FCP X, navigate to the titles browser and find BretFX Speech Bubble. Drag BretFX Speech Bubble or one of the 12 position or shape presets to the timeline.    All presets have the same controls and capabilities of the custom Speech Bubble plugin. In the viewer window, the scale and placement of Speech Bubble can be adjusted with the on screen controls.  Drag the point in the center of the ring to move the entire bubble around. Drag the ring to control the scale of the bubble. Drag the point at the end of the bubble tail to control it’s length and position. (Not applicable for “Caption” and “Thought” bubbles) Rectangle and Caption also support an additional control on the edge at side farthest from the tail that can be dragged to control the width of the shape. For other adjustments, open the inspector and choose the generator tab where all controls are.

Speech Bubble Controls
With your Speech Bubble title selected in the timeline, open the inspector (if it isn’t already) and choose the Titles tab.

Animate In, Animate Out
Checking these boxes toggles the in/out animation.  When Animate In is checked the bubble scales up and moves away from the tail as it fades in.  It has a slight bounce to it.  When  Animate Out is checked, it reverses the animation at the end of the effect.

Bubble Shape & On-Screen Controls
Choose from 8 different shapes. All shapes support on-screen control for size and position. All bubbles except “Caption” and “Thought” support controlling the length and position of the end of the tail with on-screen controls.  Rectangle and Caption also support an additional control on the edge at the side farthest from the tail that can be dragged to control the width of the shape.

Bubble Tail Direction
Controls the direction the tail points. Choose from lower left, lower right, upper left, and upper right. Further fine tune the length and position of the tail with the on-screen control.

Bubble Size
Controls the size of the bubble.  This is directly related to the on-screen control that looks like a ring. Both serve the same function.  Adjusting one adjusts the other.

Bubble Position
Controls the position of the bubble on screen.  This is directly related to the on-screen control residing in the center of the fore-mentioned ring.  Both serve the same function and adjusting one adjusts the other.

Bubble Color
Controls the color of the bubble itself.

Outline 1 Color
Controls the color of the first, inner outline.

Outline 1 Width
Controls the width of the inner outline.

Outline 2 Color
Controls the color of the second, outer outline.

Outline 1 Width
Controls the width of the outer outline.

Text
You can enter your text here, or double click the text in the viewer window.  Click on the text pane in the inspector to control font, size, outline, drop shadow, color, etc. You can control the text position by dragging the text with the mouse, or use the Text Position controls (below) for greater precision.

Text Position
Controls the position of your text within the bubble.  Position can also be controlled by moving the text with the mouse as with all FCP X titles.

Text Rotation
Control the Z rotation of the text.

Text Fade In
When this is checked, the text will fade in letter by letter as if being written on.  If you have chosen to animate your bubble in, then the text fade animation would begin immediately after the bubble animation.

Fade in Speed
Unlike the bubble animation, the text animation speed is affected by the duration of your Speech Bubble title.  Once you’ve set the duration of the Speech Bubble, use the fade in slider to tweak the speed of the text fade in animation.

CARTOON EFFECT INSTRUCTIONS

To Apply
In FCP X, navigate to the effects browser and find BretFX Cartoon Kit. Drag BretFX Cartoon Effect or one of the effect presets to a clip in the timeline.    All presets have the same controls and capabilities of the custom Cartoon Effect plugin.

Cartoon Effect Controls
Select the clip that you applied Cartoon Effect to and open the inspector (if it isn’t already). Navigate to the Cartoon Effect or chosen Cartoon Effect preset. Click the small triangle to the left of the effect name to to expose the effect controls if they aren’t already visible.

Effect Blend Mode
Controls how the Detail, Halftone, Outline and Posterization interact with each other and the source image.  Try different settings for uniquely different results.

Image Detail
Adjusts the amount of detail in the source image.

Halftone Size
Controls the size of the halftone effect.

Halftone Contrast
Adjust the sharpness of the halftone.

Halftone Strength
Adjusts the opacity of the halftone effect.  Set to 0 for no halftone effect and 100 for a stronger effect.

Ink Outline
Add a sketch-like outline to the image edges.  A smaller number is a stronger effect.  Detail and contrast will have an effect on this control as well.

Outline Smooth
Affects the harshness of the Ink Outline and blends it with the source image.

Outline Color
The color of the outline sketch.

Paper Color
The tint/hue of the underlying “paper” and source image.

Posterize
Checking this box turns on posterizing of the source image.

Posterize Amount
The higher the amount, the smaller the number of colors used in the image.  More posterization can resemble a low quality print process. Due to the high contrast nature of the cartoon effect, posterization may have to be set to a high number to see a change.

Strobe
Checking this box turns on the strobe effect and stutters the video.

Strobe FPS
Controls the stutter/frame rate of your footage without affecting the duration or speed.   Lower frame rates produce a more pronounced stutter motion.

CARTOON PANEL / CARTOON PANEL CUSTOM SHAPE INSTRUCTIONS

To Apply
In FCP X, navigate to the effects browser and find BretFX Cartoon Kit. Drag BretFX Cartoon Panel, BretFX Cartoon Panel Custom Shape, or one of the effect presets to a clip in the timeline.    Cartoon Panel and Cartoon Panel Custom Shape (and their related presets) have slightly different controls.

Cartoon Panel & Cartoon Panel Custom Shape Controls
Select the clip that you applied Cartoon Panel to and open the inspector (if it isn’t already). Navigate to the Cartoon Panel or chosen Cartoon Panel preset. Click the small triangle to the left of the effect name to to expose the effect controls if they aren’t already visible.

Source Position
Adjusts the position of the source image within the panel.

Source Scale
Adjusts the scale of the source image within the panel.

Source Rotation
Rotates the source image within the panel.

Panel Shape (BretFX Cartoon Panel only)
Choose from 5 shapes. Stack video clips on the timeline and apply a panel shape effect to each, creating a comic book style layout.

Panel Position (BretFX Cartoon Panel only)
Controls the position of your panel shape without affecting the position of the underlying image.

Panel Size (BretFX Cartoon Panel only)
Scales the size of the panel.

Panel Rotation (BretFX Cartoon Panel only)
Rotates the panel shape.

Custom Shape & Custom Shape On-Screen Controls (Cartoon Panel Custom Shape only)
Instead of having shape, position, and size controls, the cartoon panel custom shape allows you to create any 4 sided shape you wish (or even a triangle), and some great custom comic style layouts when multiple panel shapes are applied to multiple stacked video clips, with on screen controls. Control the position by dragging the center point and rotate the shape with the extended arm from the center.  The shape and size is entirely controlled by the 8 points around the edge of the panel.  Drag the corner points to corner pin the shape and control each corner individually.  Shift drag the corner points to scale it proportionately.  Drag the points on the sides to adjust two corner points at once.  Shift drag the side points to adjust two corner points at once while keeping them in line with each other. When working with a custom shape you may find inconsistent results when using the undo function.  Often the undo does occur, but the visual isn’t updated.  Click and drag around the timeline or flip the outline type back and forth between solid and rough to update.

Outline Type
Choose solid or rough outline type.  It is best to work with the panel shape first in solid outline mode and switch to the rough mode (if desired) last because the rough outline choice can affect the updating of the panel shape while editing.  Especially the custom panel shape.  Click in the timeline and drag or flip the outline type back and forth between rough and solid to update the screen.

Outline Color
The color of the panel outline.

Outline Thickness
The thickness of the outline.

Background
If checked, it enables a solid color around the panel.  Best used for the bottom most panel if you’re creating a multi-panel comic layout. For panels on higher layers, leave it unchecked to keep the area surrounding the panel transparent.

Background Color
The color of the background if the background is enabled.

Thanks and have fun!

Bret Williams
support@bretfx.com
